JDK-SFS
Features
1.Good sharpness and high cutting efficiency with long life.
2.Smooth cutting with surface and even size.
3.Stable cutting with narrow cutting gap,stone waste reduction
Technical
| Name |
Specification |
Core Thickness |
Segment Dimension |
Segment Number |
Application |
| JDK Blocking
Cutting Segment |
Φ350 |
2.2 |
40x3.5x15 |
24 |
Sandstone / Lava Stone / Volcanic Rock |
| Φ400 |
2.6 |
40x3,6x15 |
28 |
| Φ500 |
3.0 |
40x4.2x15 |
36 |
| Φ600 |
3.6 |
40x5.0x15 |
42 |
| Φ800 |
4.5 |
40x6.0x15/16 |
46 |
| Φ900 |
5.0 |
40x7.0x16 |
64 |
| Φ1000 |
5.0 |
40x7.5x16 |
70 |
| Φ1200 |
5.5 |
24x8.5x15 |
80 |
| Φ1600 |
7.2 |
24x9x15 |
108 |
| Φ1800 |
7.5 |
24x10x15 |
120 |
| Φ2000 |
8.0 |
24x11x15 |
128 |
Other specification are available upon request.
