JDK-FM
Features
1.Uniqure "fan" type segment design has good continuity,effectively reduce the distance between teeth.
2Further strengthen the effect of trimming,reduce the loss of stone
3.With high working performance,the blade would not chip or break slates while cutting
Technical
| Name |
Specification |
Core Thickness |
Segment Dimension |
Segment Number |
Application |
Note |
| JDK-FM |
Φ300 |
2.2/2.4 |
(40)43/41x3.2x8(10) |
22 |
Marble / Limestone and other soft stone |
Silent or Non Silent |
| Φ350 |
2.2/2.4 |
(40)43/41x3.2x8(10) |
25 |
| Φ400 |
2.6/2.8 |
(40)43/41x3.6x8(10) |
29 |
| Φ450 |
2.8/3.0 |
40x4x8(10) |
32 |
| Φ500 |
3.0 |
40x4x8(10) |
36 |
| Φ600 |
3.6 |
40x5.5x8(10) |
42 |
Other specification are available upon request.
